1987 Pontiac Safari Rear Door stuck

Discussion in 'General Station Wagon Discussions' started by TylerTJ, May 31, 2019.

  1. TylerTJ

    TylerTJ Active Member

    Joined:
    Jan 31, 2017
    Messages:
    73
    Likes Received:
    43
    Trophy Points:
    30
    Wagon Garage:
    1
    Has anyone had this issue with their 3rd gen B Body wagons? The tailgate will fold down, but it wont fold out, no matter how hard you twist the handle.

    Also, the third row seat is stuck in the down position, seems like the cable is connected to nothing. Can't figure out how to get it up.

  2. Silvertwinkiehobo

    Silvertwinkiehobo "Nothing is foolproof as fools are ingenious."

    Joined:
    Apr 21, 2014
    Messages:
    10,600
    Likes Received:
    1,734
    Trophy Points:
    560
    Location:
    Everett, WA
    The door problem sounds like a broken or overbent actuator rod. You'd need to lower the gate, remove the inner panel, then lock the upper latch so the window interlock switch is closed, and roll the window up/out so you can access the handle mechanism.

  3. Silvertwinkiehobo

    Silvertwinkiehobo "Nothing is foolproof as fools are ingenious."

    Joined:
    Apr 21, 2014
    Messages:
    10,600
    Likes Received:
    1,734
    Trophy Points:
    560
    Location:
    Everett, WA
    The handle should be able to unlatch the two side latches with 30-50 degrees of rotation from horizontal.

  4. joe_padavano

    joe_padavano Well-Known Member

    Joined:
    Feb 9, 2010
    Messages:
    786
    Likes Received:
    134
    Trophy Points:
    117
    Wagon Garage:
    5
    Location:
    Northern VA
    Just so we're clear, the tailgate will open like a tailgate, but not like a door, correct? Usually these wagons have the opposite problem. The issue usually has to do with worn bushings in the side hinges. This prevents the gate from shutting all the way, which prevents the interlock rods from working correctly. There is also an interlock rod on the glass that can get forced out of position - this happened on my Custom Cruiser.

    In any case, you need the Fisher Body Manual for your year, which explains the tailgate interlock system and adjustments in detail. Yes, I realize this book says Buick, Olds, and Caddy. Keep in mind that this was the time frame when GM had reorganized into two divisions - BOC and Chevy/Pontiac/GMC. The body manual still applies to all the B-body wagons for that year.

    [​IMG]

  5. annap01gt

    annap01gt Blue Safari

    Joined:
    Feb 6, 2013
    Messages:
    226
    Likes Received:
    47
    Trophy Points:
    45
    Location:
    Florida
    Also have a 87 Safari but having trouble understanding third row seat problem. My base model has a cable activated pivot on the right hand side which when the handle is pulled up allows the third row seat back to be folded down. To fold seat back up just flip rear panel up and over and fold seat back up until it locks in place by that right hand size pivot. Note that the rear panel is lockable by door key to provide secure storage in the rear well.

  6. TylerTJ

    TylerTJ Active Member

    Joined:
    Jan 31, 2017
    Messages:
    73
    Likes Received:
    43
    Trophy Points:
    30
    Wagon Garage:
    1
    The seat locks in the down position

  7. annap01gt

    annap01gt Blue Safari

    Joined:
    Feb 6, 2013
    Messages:
    226
    Likes Received:
    47
    Trophy Points:
    45
    Location:
    Florida
    You are correct. Just went out and put our 3rd seat down and back up. Forgot that the lever had to be pulled for both operations. Did not try it, but can you reach the seat down latch from the spare tire compartment ?

  8. zzzizxz

    zzzizxz Well-Known Member

    Joined:
    Jun 21, 2013
    Messages:
    652
    Likes Received:
    35
    Trophy Points:
    93
    Wagon Garage:
    2
    Location:
    Cincinnati, Ohio
    For the seat issue, I have had this problem before. You need to get in under the trim, and replace the plastic clip that attaches the release wire to the handle.
    That advice sounds really vague, I know.
    There's a wire/bar that runs from the handle, back to the latch that locks the seat in the up/down position. The wire/bar is attached to the seat by a plastic clip, and that clip will break. You have to pry up or remove the plastic trim by the release handle, find the broken clip, and replace it.
